Product Details:
Payment & Shipping Terms:
|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C | Showroom Location: | None |
|---|---|---|---|
| Condition: | New | Type: | Paper Folding Machine |
| Computerized: | Yes | Voltage: | 380V, 380V |
| Dimension(L*W*H): | 6.6mX1.1mX1.4m | Weight: | 1500 Kg |
| Warranty: | 1 Year | Production Capacity: | 250 M/min |
| Key Selling Points: | Easy To Operate | Max. Workable Width: | 600 |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Marketing Type: | Hot Product 2019 | Warranty Of Core Components: | 1 Year |
| Core Components: | Pressure Vessel, Motor, Gear, Gearbox, PLC | PLC Brand: | 3A |
| Logo: | 3A | Product Name: | Cosmetics Box Gluer Machine |
| Box Unfolds To The Maximum Size: | 600mm | Feature: | Foldable Carton |
| Use: | Fold And Stick Cosmetics Box | Suitable For Paper: | Cardboard 250g-650g |
| Way Of Folding: | Stick Single Side | Weight: | 1500KG |
| Port: | HangPu |
We are in Guangdong Province, China. We are a professional manufacturer of Folding Gluing Machine. Our folder gluers are high quality, they sold all over the world.
Product parameters
|
MODEL |
CQT-650A BOX FOLDING AND PASTING MACHINE |
| PAPER |
PAPERBOARD 250g-650g |
| MAX LINER SPEED
|
250 METER / MINUTE |
|
FEEDING PAPER |
AUTOMATIC CONTINUOUS PAPER FEEDING |
|
GLUE |
WATER SOLUBLE COLD GLUE |
|
VOLTAGE |
380V3P |
|
POWER |
4.5 KW |
|
WIGHTE |
1500KG |
|
VOLUME SIZE |
LENGTH 6.6 m * WIDE 1.1 m * HEIGHT 1.4 m |
|
BOX TYPE Straight –line box |
A PAPER SIZE |
B PAPER SIZE |
|
|
110-600mm |
50-600mm |
Performance Characte
CQT-650 Performance characteristics
1. Automatic box folder gluer machine is used for side gluing of paperboard box.
2 .It's ideal equipment for printing & packaging industry because of its stability, versatility and flexibility.
3. It's available to paste various boxes,like medicine box, cosmetics box, Tea box, toy box, mask box. glove box etc..
5. Available to count automatically.
6. The feeding part is controlled by servo motor, which is more advanced and more stable.
7. high automatic, easy and convenient for operation.
More Service details
Contact us
Questions : What is the production time after placing an order?
Answer : About 20 days.
Questions : Do you have machines in stock?
Answer : Standard type of machine, there is a large amount of inventory, special models, need to place orders customized.
Questions : What is the production time after placing an order?
Answer : Yes, just give us the destination seaport or container yard..
Questions : What is the production time after placing an order? Answer : About 20 days.
Questions : Do you have machines in stock?
Answe r: Standard type of machine, there is a large amount of inventory, special models, need to place orders customized.
Questions: Can you calculate the freight costs of our ports?
Answer : Yes, just give us the destination seaport or container yard..
We have been engaged in printing and packaging machinery for 32 years.We are a professional manufacturer of Folding Gluing Machine,Gluedispenser , Paper cutter computer programming system.. We also jointly sell All kinds of post-press packaging machinery.
