Product Details:
Payment & Shipping Terms:
|
| Applicable Industries: | Manufacturing Plant, Machinery Repair Shops, Other | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Warranty Of Core Components: | 1.5 Years | Core Components: | Engine, Gearbox, Motor |
| Condition: | New | Automatic Grade: | Automatic |
| Usage: | Paper Forming Machine | Voltage: | 380V ,Customizable: 220V Voltage |
| Dimension(L*W*H): | 5.8*0.85*1.3M | Weight: | 1000 KG |
| Warranty: | 1.5 Years | Key Selling Points: | Long Service Life |
| Warranty For Core Components: | 1.5 Years | Free Gift: | Spare Parts |
| Video Feedback Production Progress: | Prompt Delivery | Safe And Reliable: | Strong Stability |
| Support Video Teaching: | Easy To Debug And Easy To Operate | Product Name: | Small Corrugated Box Gluer Side Glue |
| Box Unfolded Widest Paper Size: | 16cm--42cm | Box Unfolded Height Paper Size: | 10cm--40cm |
| Glue Tye: | Cold Glue | Regular Model Voltage 380V: | Some Models Can Change The Voltage |
| Marketing Type: | Hot Product 2022 | Port: | HuangPu |
We are specializing in the production of folder gluers, glue sprayers, and other post-press processing equipment. The device is sturdy and durable, of good quality, stable in performance, safe and reliable, easy to install, easy to operate, and has perfect folding and sticking effects. Small size, small footprint, easy to transport.
This machine can make small corrugated boxes of various specifications. It is a hot product and is very popular with customers. It is the ideal equipment for printing and packaging industry.
Performance characteristics
1. This folder gluer is a small machine type, which can produce corrugated B.
2. This folder gluer is used to automatically paste the side of the box.
3.The paper output part is equipped with a speed regulating
mechanism and a pneumatic vibration function.The paper output belt is enlarged in width and adopts hugh-quality wear resistant belt.
4.The host part and the pressure part are controlled by the inverter.
5. The speed of the press precisely follows the speed of the host through the computer system.
6.The machine has automatic batch counting function.
7.The machine is small in size, does not occupy space, and is easy to transport.
8. It has a wide range of uses and is used to make small packaging boxes in various industries. It is an ideal paper product processing equipment.
| Model | Box type | Box unfolded size |
| CQT-580D | Straight –line box side glue corrugated box cardboard paper box
| W:160mm—420mm H: 100mm—400mm |
CQT580d
corrugated box /cardboard paper box Folder Gluer
The device is equipped with an automatic spray gun
Product parameters
| MODEL | CQT-580 D Small corrugated box gluer |
| Paper | Cardboard 250g-650g Corrugated paper B |
| Max liner speed | 220 Meter / Minute |
| Feeding paper | Automatic continuous paper feeding |
| Glue | Water soluble cold glue |
| Voltage | 380V3P |
| Power | 4.5 kw |
| Net weight | About 1100kg |
| Including packaging weight | About 1300kg |
|
Overall dimension | Host volume : 2.8m *0.85 m* 1.3m |
| Auxiliary volume : 3.0m * 0.8m * 1.3m | |
|
Package dimensions | Host volume: 3.1m * 1.15m *1.6m |
| Auxiliary volume: 3.3m * 1.1m * 1.6m |
Show details
Widen the belt, the belt
is made of high-quality, wear-resistant belt
Introduction of other equipment
800/900/1100/1300/1500
Corrugated box gluer machine series
650 / 800 Straight –line box FOLDER GLUER
530 MINI FOLDER GLUER
LOCK BOTTOM FOLDER GLUER
Company Profile
We have been engaged in printing and packaging machinery for 32 years.We are a professional manufacturer of Folding Gluing Machine,Gluedispenser , Paper cutter computer programming system.. We also jointly sell All kinds of post-press packaging machinery.
1. Who are we?
We are based in Guangdong, China, start from 2020,sell to Southeast Asia(56.00%),South America(10.00%),Africa(10.00%),South
Asia(10.00%),Oceania(5.00%),Eastern Asia(5.00%),Central America(3.00%),Western Europe(1.00%). There are total about 51-100 people
in our office.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
Folder gluer,Gluer dispensing system,folding and pasting machine,Glue dispenser,glue machine
4. Why should you buy from us not from other suppliers?
We have been engaged in printing and packaging machinery for 32 years.We are a professional manufacturer of Folding Gluing
Machine,Gluedispenser , Paper cutter computer programming system.. We also jointly sell All kinds of post-press packaging
machinery.
5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES;
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,PayPal;
Language Spoken:English,Chinese
Contact Person: Ms. Amy Chen
Tel: 8613302239101
